Offset printing CTP plate, thermal CTP plate, rinse-free CTP plate, high quality CTP plate

MOQ: 3000 square
Price: Negotiable
Standard Packaging: Packed in carton, 70 pieces per pallet
Delivery Period: 8 days
Payment Method: T/T
Supply Capacity: 2000000㎡/moth
Detail Information
Product Description
Detail Information
Place of Origin
HENAN
Brand Name
PLATE-CD
Certification
ISO9001
Model Number
CD-R
Material:
High Quality Aluminum
Rinse Time:
22S-25S
Warranty Time:
20 Months
Open Request:
Open Under Indoor Yellow Light
Maximum Size Range:
1700*1500
Coating Process:
One Coat
Product Description

Offset printing CTP plate, thermal CTP plate, rinse-free CTP plate, high quality CTP plate

Offset printing CTP plate, thermal CTP plate, rinse-free CTP plate, high quality CTP plate 0



Brand
PLATE-CD
Product Type
Thermal CTP Plate
Thickness
0.15mm, 0.25mm, 0.3mm,
Compatible Plate setter
Compatible with all the common thermal plate setter
Application Type
Extremely Long Run without Baking for UV ink Printing
Maximum Coil Width
1350mm
Spectrum wave length
830nm
Exposure Energy
110-120mj/c㎡
Developing Temperature
23-28℃
Developing Time
22-25S
Safe-light
2 hours under white light
Resolution
1-99% at 200lpi
Run Length
150000-250000(Normal lnk) 100000-200000(UV lnk)
(Actual run length may vary according to printing machine, ink, paper conditions)



Chuangda (Shenzhen) Printing Equipment Co., Ltd.
Have an efficient, rigorous and serious team.
Focus on the R & D and production of plates

thermal CTP plate have high sensitivity, good hydrophilic, well ink-water balance, Long Run-length, best market compatibility, so it is extensively usedcommercial printing and newspaper printing. Whether conventional or alcohol wet plate can output the, clear, excellently, perfectly colorful prints.

• Easy-to-use. Able to work under white light and no need to pre-heating.

• Steady Quality, Good Compatibility, Excellent dot reappearance, Long Run-length.

• Close-grained Oxidation Layer –Outstanding dot reproduction, high resolution.

• Excellent Hydrophilicity- keep ink-water balance optimally.

• Unique Photosensitive Coating-High and fast Sensitivity.



PLATE-CD www.cd-printing.com
