Place of Origin:
SHENZHEN
Brand Name:
Chuangda
Model Number:
4300
Contact Us
Video
Basic parameters of the machine:
Maximum production size: 980*880
Minimum production size: 400*350mm
Applicable sheet model: 0.15 thickness -0.4 thickness.
Resolution: 2,400dpi or 1,200dpi optional 2,540dpi or 1,270dpi (variable resolution option: the highest precision can reach 12,800dpi in the circumferential direction)
Repeatability: ±0.01mm
Output interface: optical fiber interface
Environment: allowable temperature: 15-32℃, recommended temperature: 21-28℃, relative humidity: <70%
Applicable: CTP plate, CTCP plate and double layer CTP plate.
Different models of machines have different production times and speeds.
The plate making precision is very high.
