50-60HZ Violet CTP Printing Machine Brand New / Sencond Hand

Certification
China Chuangda (Shenzhen) Printing Equipment Co., Ltd. certification
Customer Reviews
The quality of the double layer CTP plate is very good, we plan to sign a long-term cooperation agreement with your company. Please keep this quality.

—— Abdul

Computer platesetter, U864. Although it is a 2018 machine, after receiving the machine, I did not expect that the appearance is not much different from the brand new machine. The interior is very clean.

—— Hussien

I decided to increase the order quantity and my client is very happy that you brought me a high quality CTP machine.

—— Bhelt

Before buying, I am more worried about the follow-up problems of the machine. However, during the one-year cooperation with you, none of the problems I worried about appeared, and you still have a quota engineer to serve me. I will introduce other friends to you

—— Mohumend

Additional order again, double layer CTP plate.

—— Abdul

I'm Online Chat Now

50-60HZ Violet CTP Printing Machine Brand New / Sencond Hand

50-60HZ Violet CTP Printing Machine Brand New / Sencond Hand
50-60HZ Violet CTP Printing Machine Brand New / Sencond Hand 50-60HZ Violet CTP Printing Machine Brand New / Sencond Hand

Large Image :  50-60HZ Violet CTP Printing Machine Brand New / Sencond Hand

Product Details:
Place of Origin: GUANGZHOU
Brand Name: CD
Model Number: T12
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Standard export wooden box
Delivery Time: 12 days
Payment Terms: T/T
Supply Ability: 20 units/month

50-60HZ Violet CTP Printing Machine Brand New / Sencond Hand

Description
Warranty Period: One Year Machine State: Automatic Transfer Processing
Required Voltage: 220V Plate: CTP Plate
Big Size Plate: 1400*1250mm Weight: 1400KG
High Light:

60HZ CTP Printing Machine

,

Brand New CTP Printing Machine

,

50HZ violet ctp machine

CTP plate making of machine ,CTP plate machine ,CTP offset machine ,offset ctp machine




Features:

  • Applicable sheet model: 0.15 thickness -0.4 thickness.
  • Resolution: 2,400dpi or 1,200dpi optional 2,540dpi or 1,270dpi (variable resolution option: the highest precision can reach 12,800dpi in the circumferential direction)
  • Repeatability: ±0.01mm
  • Output interface: optical fiber interface
  • Environment: allowable temperature: 15-32℃, recommended temperature: 21-28℃, relative humidity: <70%



Product Description:
For plate making machines, our company has new and old machines. CTP machines and CTCP machines, split or conjoined. Choose different machines according to customer requirements.

A conventional computer plate-making machine requires a 50-square-meter room to place the machine. Keep the interior clean and tidy at all times.

Technical Parameters
Model Thermal UV
T824 T832 T848 T864 T8128 U824 U832 U848 U864 U8128
NO.of lasers 24 32 48 64 128 24 32 48 64 128
Throughput(1130*800) 13 18 23 28 45 13 18 23 28 45
Max.Min.Format MAX:1160*940 MIN:400*350 MAX:1160*940 MIN:400*350
Laser source 830nm 405nm
Resoiution 2400DPI
Loading system Automatic,Semi-Auto(Optional Auto-loader)
Plate requirement CD. 0.15-0.4 (Thermal plate) CD. 0.15-0.4 UV plate
Interface 1-bit Tiff interface and direct workflow driver,support CIP3/CIP4
Power AC220V,50-60HZ 5.5KVA
Work environment Temperature:20-25℃,Humility:40%-80%
